BUY SAFEA2G45MB0F0A https://www.utsource.net/itm/p/8648277.html
| Parameter |
Description |
| Part Number |
SAFEA2G45MB0F0A |
| Type |
TVS Diode Array (ESD Protection) |
| Package |
0402 [1005 metric] |
| Operating Temperature |
-55°C to +150°C |
| Reverse Standoff Voltage (Vrwm) |
2.8V |
| Clamping Voltage (Vc) |
7.6V at 3.3A |
| Peak Pulse Current (Ipp) |
16A (8/20 μs waveform) |
| Capacitance (C) |
0.1pF |
| Response Time |
< 1ps |
| Mounting Type |
Surface Mount |
| Polarity |
Bidirectional |
| Number of Channels |
1 |
| Compliance |
RoHS Compliant |
Instructions:
Handling Precautions:
- Handle with care to avoid damage to the device.
- Use appropriate ESD protection measures during handling and installation.
Mounting:
- Ensure proper orientation during mounting as specified by the polarity.
- Follow manufacturer’s guidelines for soldering temperature and time to prevent thermal damage.
Usage:
- This device is designed to protect sensitive electronics from ESD events.
- Install in circuits where transient voltage suppression is necessary, especially in data lines and signal paths exposed to external interfaces.
Storage:
- Store in a dry, cool place away from direct sunlight and sources of heat.
- Keep in original packaging until ready to use to maintain static protection.
Testing:
- Perform post-installation testing to ensure the device meets the required performance specifications.
- Regularly inspect for any signs of physical damage or degradation over time.
(For reference only)
