1. Overview
The Auto-select & Auto-range true-RMS digital multimeter is characterized at slim size, portable, stable performance and anti-dropping capacity. Using VA colour 6000 counts digit & analogue bar graph & measurement function indication & test input jack indication LCD monitor with character 22mm high, at the same time, the second measured can be displayed, they offer clear readings. With overall circuitry design centering on large-scale IC A/D converters in conjunction and over-load protection circuit, the meters give excellent performance and exquisite making as a handy utility instrument.
The meter can auto-select DC & AC voltage, DC & AC current, resistance and audible continuity measurement, it can display the frequency value when measure AC voltage or current.
The meter can be used to measure DC & AC voltage, DC & AC current, resistance, capacitor, frequency, duty cycle, temperature, live wire detection, Non Contact AC Voltage (NCV) detection, positive diode voltage fall and audible continuity.
1 Max Voltage between input terminal and Earth Ground: CAT Ⅲ 600V
2 Over-range Indication: display “OL” for the significant digit.
3 Automatic display of negative polarity “-” .
4 Max LCD display: VA colour 6000 counts digit.
5 Auto range control
6 Auto Power Off: When measurement exceeds 15 minutes without pressing any key, the meter will auto power off.
7 Fuse protection: 800mA/250V Fast Fuse, 10A/250V Fast Fuse
8 Power supply: 1.5V×3 “AAA” R03P battery
9 Operating Temp.: 0℃ to 40℃ (relative humidity <85%)
10 Storage Temp.:-10℃ to 50℃ (relative humidity <85%)
11 Guaranteed precision Temp.: 23±5℃ (relative humidity <70%)
12 Dimension: 167(H)×83(W)×29(D)mm.
13 Weight: Approx. 270g (including battery).
