The AirTAC AFR and BFR Series are space-saving "piggyback" units that combine the functions of a high-efficiency air filter and a precision pressure regulator into a single component. By integrating these two stages, these series reduce the overall footprint of your air preparation system, minimize potential leak points, and lower installation costs.
AFR Series: The standard compact modular series, typically used with the A-Series FRL lineup.
BFR Series: A larger-bodied, high-flow version designed for more demanding industrial applications and compatible with B-Series components.
Dual-Function Efficiency: Simultaneously removes contaminants (water, dust, scale) and regulates downstream air pressure.
Advanced Water Separation: Utilizes a specialized diversion structure to spin air and separate liquid water before it reaches the filter element.
Precision Pressure Control: Features a balanced diaphragm design for stable pressure regulation and rapid response to flow changes.
Drainage Versatility: Available in Manual, Semi-Auto, and Fully Automatic drain configurations to suit your maintenance schedule.
Tough Protective Shield: Bowls come with high-strength plastic guards (on larger sizes) to protect the Polycarbonate sight glass from impacts.
| Model | AFR1500 | AFR2000 | BFR2000 | BFR3000 | BFR4000 |
| Fluid | Air | ||||
| Port size [Note 1] | 1/8" | 1/4" | 1/4" | 3/8" | 1/2" |
| Filtering grade | 40µm or 5µm | ||||
| Pressure range | Semi-auto and automatic drain : 0.15~0.9MPa (20~130psi) Manual drain : 0.05~0.9MPa (7~130psi) | ||||
| Max. pressure | 1.0MPa (145psi) | ||||
| Proof pressure | 1.5MPa (215psi) | ||||
| Temperature range | -5~70贑 (Unfreeze) | ||||
| Capacity of drain bowl | 15CC | 60CC | |||
| Weight | 260g | 400g | |||
