The AirTAC PTL Series is the industry-standard solution for precise control of pneumatic actuator speeds. Designed with a focus on ease of use and reliability, this series features a sophisticated push-lock mechanism that allows operators to adjust airflow with a simple turn and lock the setting with a single press, preventing accidental changes due to vibration or manual error.
Constructed with high-quality nickel-plated brass and high-strength plastic, the PTL series offers excellent resistance to corrosion and environmental wear. Its "One-Touch" design ensures that tubing can be connected and disconnected rapidly, making it a favorite for high-efficiency assembly lines and maintenance-heavy environments.
Intuitive Push-Lock System: Allows for rapid adjustment and secure locking without the need for additional tools.
Precision Needle Valve: Provides linear and stable flow adjustment for smooth cylinder movement.
360° Swivel Design: The body can be rotated 360 degrees even after installation, allowing for optimal tubing orientation.
Pre-Coated Thread Sealant: All tapered threads come pre-applied with Teflon sealant to ensure a leak-proof connection from the first install.
Corrosion Resistant: Nickel-plated metal components prevent oxidation and extend the life of the fitting in humid or harsh conditions.
Clear Identification: Flow direction (Meter-out vs. Meter-in) is clearly marked on the body for error-free installation.
| Operating pressure range | 0~10kgf/cm² (0~1.0MPa) |
| Negative pressure | -750mmHg (10 Torr) |
| Proof pressure | 1.5MPa |
| Ambient and fluid temperature (贑) | -20~70贑 |
| Applicable tubing | Soft nylon or polyurethane |
| Color | Grey/Black |
