SMT ESD Magazine Rack

Precision PCB Storage & Handling Solutions

Our SMT ESD Magazine Racks are specifically designed for the safe storage, transportation, and handling of printed circuit boards (PCBs) throughout SMT production and electronics manufacturing processes.

Constructed from ESD-safe conductive materials with a durable aluminum frame, these magazine racks effectively protect sensitive PCBs from electrostatic discharge while ensuring secure handling during automated and manual production.

Compatible with most SMT assembly equipment, our magazine racks provide stable performance, adjustable width, and high durability for demanding manufacturing environments.

Product Range

• SMT Magazine Rack
• PCB Magazine Rack
• Adjustable Magazine Rack
• Automatic Loader Magazine Rack
• Unloader Magazine Rack
• High-Temperature Magazine Rack
• Cleanroom Magazine Rack
• Custom SMT Magazine Rack

Key Features

• ESD Safe Conductive Materials
• Lightweight Aluminum Frame
• Adjustable Width for Various PCB Sizes
• High Precision PCB Slot Design
• Smooth PCB Loading & Unloading
• Heat Resistant Components
• Cleanroom Compatible
• Strong & Durable Construction
• Excellent Dimensional Stability
• Long Service Life
• RoHS & REACH Compliant

Applications

Ideal for use in:

• SMT Production Lines
• PCB Assembly
• Automated Loader & Unloader Systems
• Wave Soldering
• Reflow Soldering
• AOI Inspection
• ICT Testing
• Electronics Manufacturing
• Semiconductor Production

Specifications

• Adjustable Width Design
• ESD Conductive Side Panels
• Aluminum Alloy Frame
• Multiple PCB Slot Configurations
• High Temperature Resistance Available
• Custom Slot Pitch Available
• Lightweight & Easy Handling
• Stable Mechanical Structure




Custom Manufacturing

We provide complete customization services to meet different production requirements.

• Custom Rack Dimensions
• Adjustable Width Range
• Custom PCB Slot Pitch
• Custom Slot Quantity
• High Temperature Materials
• Conductive or Static Dissipative Materials
• Company Logo Printing
• OEM & ODM Manufacturing

Why Choose Our SMT ESD Magazine Rack?

• Protects PCBs from Electrostatic Discharge
• Compatible with Most SMT Equipment
• Smooth PCB Handling & Transportation
• Durable Industrial-Grade Construction
• High Precision Manufacturing
• Easy Maintenance
• Long-Term Reliability
• Cost-Effective Production Solution
