Motorized Ultrasonic Testing Probe of Ultrasonic Hardness Tester with latest ultrasonic sensor technology, accurate hardness value measurement, and one key fast measuring operation.
Introduced latest ultrasonic sensor technology
Obtain accurate hardness value without auxiliary devices
Excellent human engineering design easy to hold
Quick and accurate measuring for edge and fixed position of specimen
Micro indentation, no destructive for specimen
Motorized control, one key fast measuring
Eliminate hand shake error by manual probe, higher accuracy and repeatability
More suitable for thin pieces, coating layer hardness
| Commodity | Motorized Ultrasonic Testing Probe of Ultrasonic Hardness Tester | |||
| Probe Type | MP-300 | MP-500 | MP-800 | MP-1000 |
| Code# | 882-221 | 882-231 | 882-241 | 882-251 |
| Remark Optional | Optional | Optional | Optional | Optional |
| Loading Force | 3N | 5N | 8N | 10N |
| Diameter | 46mm | 46mm | 46mm | 46mm |
| Length | 200mm | 200mm | 200mm | 200mm |
| Oscillating Rod Diameter | 3.7mm | 3.7mm | 3.7mm | 3.7mm |
| Min weight of test material | 0.3kg | 0.3kg | 0.3kg | 0.3kg |
| Min thickness of | 2mm | 2mm | 2mm | 2mm |
| test material | ||||
Contact us today to inquire about the Motorized Ultrasonic Testing Probe of Ultrasonic Hardness Tester and enhance your hardness testing capabilities.
