New technology digital clamp meter, hand-held non-slipergonomic design, with multi-function, high precision, highperformance, anti-drop, safety and stability, etc., can accuratelymeasure AC/DC current,AC/DC voltage, high voltage alarm,frequency , continuity, diode, resistance, capacitor, NCV and Livewire detection, etc., and has misoperation circuit protection,suitable for electrical maintenance and repair of professionalelectricians, and is a must-have for factory and distributioncontrol system maintenance.
Electrician power distribution technology installation and maintenance. Industrial construction, factory production and distribution system installation, maintenance and repair.
| Function / Model | FR207C | FR207D | Accuracy |
|---|---|---|---|
| AC Current (A) | 60 / 600 / 1000A | 60 / 600 / 1000A | ±(2%+5) |
| INRUSH Current (A) | 60 / 600 / 1000A | 60 / 600 / 1000A | ±(2%+5) |
| DC Current (A) | 60 / 600 / 1000A | 60 / 600 / 1000A | ±(2%+5) |
| DC High Voltage (V) | 1000V | 1700V | ±(0.5%+5) |
| AC High Voltage (V) | 1000V | 1000V | ±(0.5%+5) |
| LowZ AC / DC Voltage (V) | 100 ~ 1000V | 100 ~ 1000V | ±(1.5%+5) |
| ACV / Bandwidth (Hz) | 1kHz | 1kHz | – |
| ACA / Bandwidth (Hz) | 60HZ | 60HZ | – |
| Frequency (Hz) | 10MHZ | 20MHZ | ±(0.5%+5) |
| Resistance (Ω) | 600Ω / 6kΩ / 60kΩ / 600kΩ | 600Ω / 6kΩ / 60kΩ / 600kΩ | ±(1%+5) |
| 6MΩ / 60MΩ | 6MΩ / 60MΩ | ±(2%+5) | |
| Capacitance (F) | 60nF ~ 600nF ~ 600uF | 60nF ~ 600nF ~ 600uF | ±(4%+5) |
| 6000uF / 60000uF | 6000uF / 60000uF | ±(8%+5) | |
| Temperature (℃) | – | 1000°C | ±(1.5%+4) |
| Temperature (! ) | – | 1832°F | ±(2%+5) |
| FEATURES | |||
| Display Counts | 6000 | ||
| Auto Range | ● | ||
| True RMS | ● | ||
| ACA PEAK | ● | ||
| ACV VFD | ● | ||
| Continuity / Diode | ● | ||
| NCV (Red LED Flashing) | ● | ||
| AC Live | ● | ||
| Max / Min | ● | ||
| Zero / Rel | ● | ||
