Lohand ZY-360 Multiparameter Water Quality Analyzer

ZY-360 Multi-parameter Water Quality Analyzer,as the core product of the'Lohand' water quality measurement ecosystem,adopts high-brightness quasi-parallel cold light source,with the features of stable performance,convenient operation,advanced optical measurement structure,long lifespan,low cost in maintenance,high precision,fast measurement,accurate data and other characteristics. The instrument has a new wireless remote data transmission function,compatible with major loT platform(Baidu,Tencent,Ali etc.),as its data can be browsed intuitively and conveniently on mobile phones,PCs,and loT platforms.



Multi-parameter Water Quality Analyzer ZY-360

*40+ pre-made curves

*Add integrated turbidity/suspended solids measurement module



Introduction

ZY-360 Multi-parameter Water Quality Analyzer,as the core product of the Lohand water quality measurement ecosystem,adopts high quality high-brightness quasi-parallel cold light source,with the features of stable performance,convenient operation,advanced optical measurement structure,long lifespan,low cost in maintenance,high precision,fast measurement,accurate data and other characteristics.



The instrument has a new wireless remote data transmission function,compatible with major ioT platform(Baidu,Tencent,Ali etc),and its data can be browsed intuitively and conveniently on mobile phones,PCs,and to platforms.



Application

It's widely used in water quality analyzing in scientific research institutes,sewage engineering,water environment analyzing,petrochemical,metallurgical steel,biopharmaceuticals,food and beverage,wool spinning printing and dyeing,electronic machinery,aquaculture,photovoltaics,leather,paper making and other fields.



Technical Data

No.	Parameters	Measuring range(mg/L)	Detection limit(mg/L)
1	COD	10-15000	3
2	Ammonia Nitrogen	0.02-50	0.005
3	Total Phosphorus	0.02-100	0.005
4	Total Nitrogen	0.5-150	0.2
5	Permanganate Index	0.5-25	0.5
6	Hexavalent Chromium	0.02-3	0.02
7	Total Chromium	0.02-3	0.02
8	Nickel	0.05-5	0.05
9	Total NIckel	0.05-5	0.05
10	Zinc	0.05-5	0.05
11	Total Zinc	0.1-5	0.1
12	Copper	0.02-2	0.02
13	Total Copper	0.02-2	0.02
14	Ferrous Iron	0.02-3	0.02
15	Total Iron	0.02-3	0.02
16	Divalent Manganese	0.02-5	0.02
17	Manganese	0.5-20	0.5
18	Total Manganese	0.5-20	0.5
19	Cadmium	0.03-1	0.03
20	Total Cadmium	0.03-1	0.03
21	Aluminum	0.02-0.5	0.02
22	Silicon	0.02-100	0.02
23	Chloride	8-500	8
24	Cyanide	0.005-0.5	0.005
25	Fluoride	0.02-2	0.02
26	Sulfide	0.004-1	0.004
27	Valatile Phenol	0.05-5	0.05
28	Nitrite	0.005-0.3	0.005
29	Nitrate	0.5-40	0.5
30	Phosphate	0.02-2	0.02
31	Dissolved Oxygen	1-20	1
32	Residual Chlorine	0.02-12	0.02
33	Total Chlorine	0.02-12	0.02
34	Chlorine Dioxide	0.02-5	0.02
35	Total Hardness	0.5-500	0.5
36	Total Alkalinity	5-3000	5
37	Ozone	0.01-2.5	0.01
38	Urea	0.1-20	0.1
39	Cyanuric Acid	5-160	5
40	Aniline	0.01-2	0.01
41	Chroma	70-500 Pt-Co	70 Pt-Co
42	pH	0-14pH	/
43	Formaldehyde	0.02-1.5	0.02
44	Suspended Matter	0.1-1000	0.1
45	Turbidity	0.1-1000NTU	0.1NTU









Basic data



Item	Specification
Warranty	1 year
Customized support	OEM
Place of Origin	Hzngzhou
Brand Name	Lohand
Product name	Multi-parameter Water Quality Analyzer
Absorbance measuring range	0-3.5Abs
Measuring accuracy	≤±5%
Repeatability	≤±3%
Optical Path Stability	≤0.002Abs/30min
Absorbance resolution	0.001Abs
Operation repeatability	≤±0.005Abs
pH-temperature electrode measuring range	0-14 pH,0-60℃
Data memory	10000sets
Power supply	DC12V/5A
