Parameter	Symbol	Conditions	Min	Typ	Max	Unit
Forward Voltage	VF	IF = 20 mA		1.2	1.6	V
Peak Forward Current	IFP	tP = 1 ms, Repetition Rate = 100 Hz		30		mA
Continuous Forward Current	IF	Ta = 25°C		20		mA
Reverse Voltage	VR			5	7	V
Isolation Voltage	VIORM	Test Condition		2500		Vrms
Output Leakage Current	IOL	VOUT = 0 V, Ta = 25°C	-1		1	μA
Propagation Delay Time	tpHL,tpLH	VOUT = 1.5 V, IOH = -4 mA, IOL = 16 mA, Ta = 25°C		1.8		μs
Pulse Width Distortion	tpwd	VOUT = 1.5 V, IOH = -4 mA, IOL = 16 mA, Ta = 25°C		0.2		μs

Handling and Storage:
- Store in a dry place away from direct sunlight.
- Handle with care to avoid damage to the leads and body.
Mounting:
- Ensure proper alignment of the component during soldering.
- Use appropriate temperature and time settings for soldering to avoid thermal stress.
Electrical Connections:
- Connect the input side (anode and cathode) correctly to the driving circuit.
- Ensure the output side (collector and emitter) is properly connected to the load circuit.
Operational Considerations:
- Do not exceed the maximum ratings specified in the table.
- Keep the ambient temperature within the operational limits to ensure reliable performance.
- For applications requiring high reliability, derate the forward current and voltage specifications as necessary.
Testing:
- When testing the device, adhere to the test conditions provided in the parameter table for accurate measurements.
- Avoid prolonged exposure to maximum voltages and currents during testing to prevent damage.
Safety Precautions:
- The isolation voltage rating must be respected to ensure safety and prevent electrical shock.
- Always use protective equipment when handling electronic components.

Refer to the datasheet for detailed specifications and additional information specific to your application.

(For reference only)
