| Parameter |
Symbol |
Conditions |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
VF |
IF = 10 mA |
- |
1.2 |
1.5 |
V |
| Reverse Breakdown Voltage |
VR |
IR = 5 mA |
- |
- |
5 |
V |
| Peak Forward Current |
IFM |
Pulse Width ≤ 1 ms |
- |
- |
30 |
mA |
| Operating Temperature Range |
TOPR |
|
-40 |
- |
85 |
°C |
| Storage Temperature Range |
TSTG |
|
-55 |
- |
125 |
°C |
Instructions for Use:
Mounting and Handling:
- Handle the TLP421GB with care to avoid mechanical damage.
- Ensure proper heat dissipation if used in high-temperature environments.
Electrical Connections:
- Connect the device according to the specified pin configuration.
- Ensure that the forward current does not exceed the peak forward current (IFM) rating, especially during pulse operations.
Environmental Considerations:
- Operate within the specified operating temperature range to ensure reliable performance.
- Store in environments where temperatures do not exceed the storage temperature range.
Safety Precautions:
- Avoid exceeding the reverse breakdown voltage (VR) to prevent potential damage.
- Regularly inspect connections and mounting to ensure secure and stable operation.
Testing and Troubleshooting:
- Test the forward voltage (VF) under specified conditions to verify correct operation.
- If any parameter deviates significantly from typical values, check for issues in the circuit or environmental factors affecting performance.
(For reference only)
