TLP261J(F): Top Choice in United States (USA) Utsource Holding Company Limited

Description

Parameter	Symbol	Min	Typ	Max	Unit	Condition
Forward Voltage	V_F	-	1.2	1.5	V	IF = 20 mA
Reverse Breakdown Voltage	V_BR	5	-	7	V	IR = 10 μA
Continuous Forward Current	I_F	-	-	30	mA	Ta = 25°C
Peak Forward Current	I_F(surge)	-	-	100	mA	t = 10 ms, Repetition Rate = 100/s
Storage Temperature	T_STG	-40	-	85	°C	-
Operating Temperature	T_A	-40	-	85	°C	-
Output Leakage Current	I_OL	-	1	5	μA	V_O = 0 V, T_A = 25°C
Output Turn-ON Time	t_on	-	2	5	μs	V_I = 5 V, R_L = 1 kΩ, C_L = 100 pF
Output Turn-OFF Time	t_off	-	2	5	μs	V_I = 0 V, R_L = 1 kΩ, C_L = 100 pF

Mounting and Handling:
- Handle the TLP261J(F) with care to avoid mechanical stress.
- Ensure proper grounding to prevent electrostatic discharge (ESD).
Power Supply:
- Apply the forward current (I_F) within the specified limits to avoid overheating and damage.
- Ensure the reverse voltage (V_BR) does not exceed the maximum rating.
Temperature Considerations:
- Operate the device within the specified temperature range (T_A and T_STG) to ensure reliable performance.
- Provide adequate heat dissipation if operating at high temperatures or high currents.
Signal Integrity:
- Use appropriate decoupling capacitors to filter out noise and ensure stable operation.
- Keep signal traces short to minimize inductance and capacitance effects.
Storage:
- Store the device in a dry, cool place to prevent moisture damage.
- Follow ESD handling guidelines during storage and transportation.
Testing:
- Use a constant current source to test the forward voltage (V_F).
- Measure the output leakage current (I_OL) under no-load conditions to verify proper operation.
Safety:
- Ensure all connections are secure and insulated to prevent short circuits.
- Follow all relevant safety standards and regulations when designing and testing circuits.

(For reference only)
