Description
The Hypertherm Powermax30 XP is a compact and versatile plasma cutter featuring dual-voltage operation, precision FineCut technology, and powerful cutting and gouging capabilities for a wide range of metal fabrication applications.
Highlighted product features:
Easy to use
• Simplified operations get you cutting quickly and easily
• Small and lightweight, the Powermax30 XP delivers whenever and wherever you need it
• Quickly cut metal grate or rusted metal without retriggering with the continuous pilot arc feature
Versatile
• Plug into any 120 or 240 V circuit (convenient Auto-Voltage™ technology and plug adapters included)
• Two-in-one design for maximum versatility with high power for thicker metals and FineCut consumables for high-quality cuts on thinner metals Industry-leading reliability
• Powermax plasma cutters are known to last decades in the field, minimizing maintenance and downtime
• Torches are engineered for rugged industrial environments Each Powermax component is tested to perform reliably in demanding conditions
Cut capacities
| Cut capacity |
Thickness |
Cut speed |
| |
Cutting |
|
| Recommended |
10 mm (3/8") |
500 mm/min (20 ipm) |
| |
12 mm (1/2") |
250 mm/min (10 ipm) |
| Severance |
16 mm (5/8") |
125 mm/min (5 ipm) |
| Torch output** |
3.75 kW |
| |
30 A x 125 V ÷ 1000 W = 3.75 kW |
**Higher output voltage at the torch plus efficiently designed consumables result in a faster, cleaner cut.
SPECIFICATIONS - CSA (for use in the Americas and Asia, except China)
SPECIFICATIONS - CE (for use in Europe, Australia & New Zealand - RCM, Serbia, UK - UKCA, Ukraine, and other countries where accepted)
SPECIFICATIONS - CCC (for use in China)
| Input voltages (± 10%) |
120–240 V, 1-PH, 50/60 Hz |
| Input current @ 3.8 kW |
120–240 V, 1-PH, 25.5-18.8 A |
| Output current |
15–30 A |
| Rated output voltage |
125 VDC |
Duty cycle @ 40° C (104° F)
|
35%, 240 V |
| 20%, 120 V |
| Open circuit voltage (OCV) |
256 VDC |
| Weight with 4.5 m (15') torch |
9.5 kg (21.4 lbs) |
General specifications:
Dimensions with
handles |
356 mm (14.0") D; 140 mm (5.5") W; 292
mm (11.5") H |
| Gas supply |
Clean, dry, oil-free air or nitrogen |
Recommended gas inlet flow rate/
pressure |
113.3 l/min (4 scfm) @ 80 psi (5.5 bar) |
| Input power cable length |
3 m (10') |
| Power supply type |
Inverter – IGBT |
Engine drive
requirement |
5.5 kW for full 30 A output |
| Recyclability |
100% |
| Warranty |
Power supply: 6-year, Torch: 1-year |
